Micro Perforated Acoustic Panel with Fireproof HPL Finish for Architectural Spaces
| Place of Origin | Guangzhou,china |
|---|---|
| Brand Name | WINEGO |
| Certification | CE,FSC,France A+ |
| Model Number | PAE2.2/0.5-12/15 |
| Minimum Order Quantity | 100 SQM |
| Packaging Details | 122*244*4cm per carton or other, LOGO service for big order |
| Delivery Time | 2 weeks |
| Payment Terms | TT :50% deposit Balance before shipment |
| Supply Ability | 10000sqm per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Sound Absorption | 0.8 NRC | Material | Red Fire-resistant MDF/Standard MDF/ |
|---|---|---|---|
| Size | W600/1200*L600/1200/2400*T12/15/18mm | Application | Commercial Buildings, Auditoriums, Theaters |
| Perforation Pattern | Micro | Acoustic Performance | Highly Effective |
| Finish | HPL | Color | WINEGO Color Card |
Product Description
Micro Perforated Acoustic Panel with Fireproof HPL Finish for Architectural Spaces
Description:
This advanced micro-perforated panel is engineered for optimal sound absorption through strategically placed holes measuring 0.4 to 1mm in diameter. These tiny openings, combined with precision rear cavities, generate Helmholtz resonance effects to diminish reverberation and noise across a broad frequency range. Crafted from premium sustainable materials, the panel complies with modern fire safety and eco-standards. With a choice of decorative veneers or melamine coatings, it balances acoustic function with aesthetic flexibility for use in conference halls, offices, studios, and upscale residences.
Feature:
Broad Frequency Absorption: Tailored to reduce echo and ambient noise across mid to low frequencies using Helmholtz resonator principles.
Architectural Adaptability: Easily mounts to ceilings and walls while maintaining the design integrity of the room.
Eco and Fire Safe: Made from fire-rated materials with minimal environmental impact, aligning with green building standards.
Customizable Appearance: Wide array of textures, finishes, and panel dimensions for bespoke design integration.
Specifications:
| NAME | Micro-Perforated acoustic panel |
| FINISH | Veneer/Melamine/HPL fire-proof/PU paint |
| BASE MATERIALS | MDF/A grade MGO/Solid wood |
| MODEL |
PAE3/1-12/15,other customized model |
| Size |
W590/1200*L590/1200/2420*T15/18mm |
| environmental protection | E1 |
| warranty | 2 years |
| INSTALL | Keel/Nail gun |
| MIN.ORDER | 100 SQM |
| PACKAGE DETAILS |
W1200mm*L2400mm*T 14mm: 2 pieces per pack,the size of the single package is W1220m*L2415mm*T40mm,95.4kg per pack. |
| Delivery time | 2 weeks |
| Original place | Guangzhou,china |
| Payment term |
TT :50% deposit |
| Additional service | OEM |
| NRC | 0.8 |
| Certificate | CE,FSC,France A+ |
| Brand | WINEGO |
| Project Solution Capability | Project Design,3D model design,Graphic design,Material Production,Shipping and Deliver |
| Design Style | Modern |
| After-sale Service | Online technical support,Return and Replacement,Installation Instruction |
