Fire Proof Elevate Acoustic Design Grooved Panels For Premium Sound Environments
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | Winego |
| Certification | CE, FSC, France A+,ISO9001 |
| Model Number | GA-13/3 |
| Minimum Order Quantity | 200 |
| Price | USD7.88-18.88 PER sqm |
| Packaging Details | 249*15*18cm with 10pcs per carton |
| Delivery Time | 15-21 working days |
| Supply Ability | 10000sqm per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Grooved MDF Wood Fiber Acoustic Panel | Base Material | Fire Retardand MDF/ Standard MDF / A GRADE BOARDE |
|---|---|---|---|
| Surface Finish | Veneer / Melamine / HPL | Back | Black Fleece / Black Fabric/Soundtex Fleece |
| Standard Size | 133/197*2440mm Standard Other Customized | Thickness | 15/18/21mm |
| NRC | 0.85 | Type | Sound Absorption |
| Application | Theater,Office, Auditorium Etc. | Installation | By Nail Gun Or Clip System |
| Environmental Protection | E1 Or E0 | ||
| Highlight | Fire Proof Grooved Acoustic Panels,Grooved Panels For Premium Sound |
||
Product Description
Elevate Acoustic Design with Winego Grooved Panels for Premium Sound Environments
Description:
This is the full description text for document number 1. It includes details about the grooved acoustic panel’s materials, design, application, and acoustic performance. Each description is tailored to highlight different spatial use cases and design needs.
Product Features:
• Superior acoustic absorption (NRC up to 0.85)
• Certified fire resistance (BS476-PART 7 CLASS 1)
• Custom finishes and configurations
• Eco-friendly and sustainable materials
• Effective sound control in various settings
Specificatins:
| Name | Grooved MDF Wood Fiber Acoustic Panel |
| Base Materials | MDF/FR MDF/HDF |
| Finish | Veneer/Melamine/HPL fire-proof |
| Model | GA-13/3 |
| Size | W 133/197*L 2440mm |
| Environmental protection | E1 or E0 |
| Warranty | 2years |
| Installation | Nail gun / Keel |
| MIN. order quantity | 200 SQM |
| Packing details | 10pcs per CTN CTN size: 2490*150*180mm |
| Delivery time | 3 weeks |
| Original place | Guangzhou,China |
| Payment term |
TT :50% deposit Balance before shipment |
| Additional service | OEM |
| NRC | 0.85 |
| Certificate | CE,FSC,France A+,ASTM-E84 1,BS476 PART7 |
| Brand | Winego |
Application:
Multi-functional hall
Conference room
Auditorium
Opera house
Concert hall
TV Station
Music hall
Piano room
Installation Instructions:
Method A:
-
Attach the keel to the wooden battens using gun nails.
-
Secure the panels by inserting clips into the keel.
-
Begin installation from the bottom left, working your way up and to the right.
-
Adjust the clips as necessary to ensure proper alignment.
-
Maintain a 3mm gap between the edges of each panel.
Method B:
-
Level the wall with wooden battens.
-
Fill the space with fiberglass acoustic wool for added sound absorption.
-
Secure the panels onto the battens using gun nails.
FAQ:
1. What sizes are available?
- Standard sizes are 133*2440 mm and 197*2440 mm with thicknesses of 12mm, 15mm, and 18mm.
2. What materials are the panels made from?
- Options include MDF, MgO boards, carbon fiber boards, and solid wood.
3. Can I customize the panel finishes?
- Yes, finishes can be customized with melamine, veneer, HPL, and more.
4. What is the NRC of these panels?**
- The NRC can reach up to 0.9, providing excellent sound absorption for both commercial and privated space.
