High-End Grooved Acoustic Wall Panels with Fire Resistance for Modern Interiors
| Place of Origin | Guangzhou, China |
|---|---|
| Brand Name | Winego |
| Certification | CE, FSC, France A+,ISO9001 |
| Model Number | GA-13/3 |
| Minimum Order Quantity | 200 |
| Price | USD7.88-18.88 PER sqm |
| Packaging Details | 249*15*18cm with 10pcs per carton |
| Delivery Time | 15-21 working days |
| Supply Ability | 10000sqm per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Grooved MDF Wood Fiber Acoustic Panel | Base Material | Fire Retardand MDF/ Standard MDF / A GRADE BOARDE |
|---|---|---|---|
| Surface Finish | Veneer / Melamine / HPL | Back | Black Fleece / Black Fabric/Soundtex Fleece |
| Standard Size | 133/197*2440mm Standard Other Customized | Thickness | 15/18/21mm |
| NRC | 0.85 | Type | Sound Absorption |
| Application | Theater,Office, Auditorium Etc. | Installation | By Nail Gun Or Clip System |
| Environmental Protection | E1 Or E0 | ||
| Highlight | High-End Grooved Acoustic Wall Panels,Modern Interiors Acoustic Wall Panels,Fire Resistance Acoustic Wall Panels |
||
Product Description
High-End Grooved Acoustic Wall Panels with Fire Resistance for Modern Interiors
Description:
Elevate your acoustic environment with our fire-resistant grooved panels, thoughtfully designed for modern architectural spaces. These panels provide a perfect balance of visual appeal and acoustic efficiency, controlling reverberation and enhancing audio clarity. Whether for a conference hall, recording room, or premium retail space, the customizable design ensures integration into diverse interior styles while meeting stringent fire safety standards.
Product Features:
• NRC up to 0.85 for optimal noise reduction
• Fire-rated under BS476-Part 7, Class 1 standards
• Flexible installation options and layout configurations
• Green materials with low VOC emissions
• Ideal for contemporary workspaces, performance areas, and hospitality venues
Specificatins:
| Name | Grooved MDF Wood Fiber Acoustic Panel |
| Base Materials | MDF/FR MDF/HDF |
| Finish | Veneer/Melamine/HPL fire-proof |
| Model | GA-13/3 |
| Size | W 133/197*L 2440mm |
| Environmental protection | E1 or E0 |
| Warranty | 2years |
| Installation | Nail gun / Keel |
| MIN. order quantity | 200 SQM |
| Packing details | 10pcs per CTN CTN size: 2490*150*180mm |
| Delivery time | 3 weeks |
| Original place | Guangzhou,China |
| Payment term |
TT :50% deposit Balance before shipment |
| Additional service | OEM |
| NRC | 0.85 |
| Certificate | CE,FSC,France A+,ASTM-E84 1,BS476 PART7 |
| Brand | Winego |
Application:
Multi-functional hall
Conference room
Auditorium
Opera house
Concert hall
TV Station
Music hall
Piano room
Installation Instructions:
Method A:
-
Attach the keel to the wooden battens using gun nails.
-
Secure the panels by inserting clips into the keel.
-
Begin installation from the bottom left, working your way up and to the right.
-
Adjust the clips as necessary to ensure proper alignment.
-
Maintain a 3mm gap between the edges of each panel.
Method B:
-
Level the wall with wooden battens.
-
Fill the space with fiberglass acoustic wool for added sound absorption.
-
Secure the panels onto the battens using gun nails.
FAQ:
1. What sizes are available?
- Standard sizes are 133*2440 mm and 197*2440 mm with thicknesses of 12mm, 15mm, and 18mm.
2. What materials are the panels made from?
- Options include MDF, MgO boards, carbon fiber boards, and solid wood.
3. Can I customize the panel finishes?
- Yes, finishes can be customized with melamine, veneer, HPL, and more.
4. What is the NRC of these panels?**
- The NRC can reach up to 0.9, providing excellent sound absorption for both commercial and privated space.
